This All in one Packs a F4 Flight controller and 4 35Amp BLHeli32 speed controllers with Telemetry Output functionality wired up inside the board. Supporing BetaFlight 32/16 Loop times with a ICM20608 and powerfull F411. Flat bottom for easy installs, and 4000uf of capacitors on board. 95% of users will find NO need for any extra bulky caps.Â
The Nox AIO Flight Controller offers next-generation technologies in a single compact and reliable board. This board represents a unique mix of overall size and mounting pattern. Whereas most boards this size would have 30x30mm mounting, this uses the smaller standard of 20x20mm mounting holes, allowing it be to be used on a wide range of frames.
With 4000uf capacitors on board, you know you’ll get clean signal throughout. All of this weighs just 22g with the total size of the board being 48x39mm with 20mm mounting holes.
48mmx39mm total dimensions
20x20mm mounting holes
weight = 20g
Flight Controller Features
Betaflight OSD
STM32F411 MCU
ICM20608 MPU/Gyro – It’s also replaceable
Barometer
5V BEC with LC filter (500ma)
4000uf capacitors onboard – No extra caps
Â
4in1 ESC Features
BLHeli32 – The 32-bit architecture that we’ve come to expect
DSHOT 1200
35A Per motor
 esc Telemetry functionality
ESC upgradeable
Â
Nox V2.18 AIO Flight Controller (F4 FC, 4X35A, BLHeli32)
